Eye Hook Anchor

Eye Hook Anchor

Ferry International's eye hook anchors are engineered for critical lifting, rigging, and mounting applications where safety and reliability cannot be compromised. These heavy-duty eye bolts feature precision-machined closed eyes and high-strength threading for maximum load capacity in concrete and metal substrates.

Key Features :

โœ“ Secure Lifting Points - Closed eye design prevents accidental disconnection
โœ“ Heavy-Duty Construction - Engineered for high-load applications
โœ“ Versatile Mounting - Compatible with concrete and metal surfaces
โœ“ Professional Grade - Meets industrial safety standards
โœ“ Easy Installation - Standard threading for quick setup



Request Callback

Order In Bulk

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

Description

What Are Eye Hook Anchors?

Eye hook anchors (also called concrete eye bolts or lifting eye anchors) are specialized fastening devices featuring a closed eye loop at one end and machine threading at the opposite end. These professional-grade anchors create secure attachment points for ropes, cables, chains, and lifting equipment in permanent installations.


Technical Specifications & Load Data

Available Eye Hook Anchor Sizes



Size

Length

 (mm)

Hole Diameter

(mm)

Tightening Torque

(Nm)

M6

50

12

8

M8

60

14

15

M10

70

16

30

M12

95

20

40

NOTE: Measurements are subject to tolerances wherever applicable.

Material Options & Finishes

Zinc Plated Steel Eye Hooks

  • Standard grade for indoor lifting applications
  • Corrosion resistant coating for extended life
  • Cost-effective solution for general purpose use

304 Stainless Steel Eye Hooks

  • Enhanced corrosion resistance for outdoor use
  • Food-grade applications approved
  • Superior durability in humid environments

316 Stainless Steel Eye Hooks

  • Maximum corrosion resistance for marine applications
  • Chemical processing plant approved
  • Highest grade available for critical environments



Professional Applications & Industries

Construction & Structural

  • Concrete lifting points for precast elements
  • Structural steel rigging and positioning
  • Temporary lifting anchors during construction
  • Safety line attachment points for fall protection

Industrial & Manufacturing

  • Material handling and overhead lifting
  • Equipment positioning and installation
  • Assembly line rigging points
  • Maintenance access anchor points

Marine & Offshore

  • Dock hardware and mooring applications
  • Marine rigging and equipment securing
  • Offshore platform anchor points
  • Boat lifting and hauling systems

Entertainment & Events

  • Stage rigging and lighting suspension
  • Sound equipment hanging points
  • Temporary structure anchoring
  • Event setup and breakdown rigging



Installation Guide & Safety Requirements

Pre-Installation Safety Check

  • Verify substrate strength and suitability
  • Calculate total load including safety factors
  • Inspect anchor for defects or damage
  • Ensure proper PPE is worn during installation


Installation Process

Step 1: Substrate Preparation

  • Mark anchor location accurately
  • Drill hole to specified diameter and depth
  • Clean hole thoroughly of debris
  • Verify hole perpendicularity

Step 2: Anchor Installation

  • Insert eye hook anchor through substrate
  • Apply thread locker if specified
  • Tighten to specified torque using calibrated tools
  • Verify eye orientation for intended load direction

Step 3: Load Testing

  • Perform proof load test at 125% of working load
  • Inspect for deformation or substrate failure
  • Document test results for safety records
  • Mark anchor with load rating if required

Critical Safety Requirements

Load Calculations:

  • Never exceed working load limit (WLL)
  • Apply appropriate safety factors (minimum 4:1)
  • Consider dynamic loads and shock loading
  • Account for angular loading effects

Inspection Requirements:

  • Visual inspection before each use
  • Periodic load testing per safety standards
  • Replace if wear, deformation, or corrosion evident
  • Maintain inspection records for compliance



Load Capacity & Engineering Data

Working Load Limits (WLL)

Straight Pull Loading:

  • M6: 150 kg maximum working load
  • M8: 280 kg maximum working load
  • M10: 450 kg maximum working load
  • M12: 650 kg maximum working load

Angular Loading Considerations:

  • 45ยฐ angle: Reduce WLL by 25%
  • 60ยฐ angle: Reduce WLL by 50%
  • Side loading: Maximum 20% of straight pull WLL

Safety Factors & Standards

  • Design factor: 4:1 minimum (Breaking load รท WLL)
  • Proof load testing: 2.5 ร— WLL
  • Compliance with international lifting standards
  • Regular inspection intervals are recommended



Quality Assurance & Certifications

Manufacturing Excellence

  • Precision-machined eye openings for smooth operation
  • Heat-treated threading for maximum strength
  • Load tested during the manufacturing process
  • Dimensional accuracy verified on every batch

Safety Certifications

  • Compliant with international lifting standards
  • Third-party load testing verification available
  • Material certificates provided with shipment
  • Traceability documentation for critical applications

Quality Control Process

  • Raw material verification and testing
  • In-process dimensional inspection
  • Final load testing before shipment
  • Statistical process control monitoring



Selection Guide & Engineering Support

How to Select the Right Eye Hook Anchor

Load Requirements:

  • Calculate maximum expected load, including dynamics
  • Apply appropriate safety factors
  • Consider load direction and angles
  • Account for environmental factors

Material Selection:

  • Indoor applications: Zinc-plated steel
  • Outdoor/humid: 304 stainless steel
  • Marine/chemical: 316 stainless steel
  • Food processing: 304/316 stainless steel

Size Considerations:

  • Eye opening must accommodate attachment hardware
  • The thread length must provide adequate engagement
  • Overall length suitable for substrate thickness

Free Engineering Support

  • Load calculation assistance and verification
  • Material selection guidance for applications
  • Installation consultation and troubleshooting
  • Custom specifications for special requirements
